Binder® Model UF V 350, Ultra-low Temperature Freezers with Climate-Neutral Refrigerants, 25.9 Cu Ft (734 L), 400V

Binder® Model UF V 350, Ultra-low Temperature Freezers with Climate-Neutral Refrigerants, 25.9 Cu Ft (734 L), 120V

Binder™

SKU:

9020-0454

$17,793.00

Net 30 Terms Available

Earn points on this purchase

The BINDER ultralow temperature freezer ensures safe long-term storage of samples at a temperature of -86°C. It is based on a multi-stage security concept, which offers everything from reliable operation to ease of use and system integration. Temperature Range: -86°C to -40°C Lowest energy consumption in its class Powerful cascade …

Quantity:

*We accept purchase orders from private, public, educational, & government institutions

Current Stock:

Request a Quote Request a Sample

Brochure

Operating Manual

Data Sheet

Technical specifications

Imperial Metric

Article Number	9020-0453	9020-0454	9020-0455
Designation	UFV350-230V	UFV350UL-120V	UFV350UL-240V
Option model	Standard	Standard	Standard

Article Number	9020-0453	9020-0454	9020-0455
Temperature range	-90...-40 °C	-90...-40 °C	-90...-40 °C
Temperature uniformity at -80°C	3.5 ± K	3.5 ± K	3.5 ± K
Temperature fluctuation at -80°C	4.0 ± K	4.0 ± K	4.0 ± K
Cooling down time from 22°C to -80°C	210 min	210 min	210 min

Article Number	9020-0453	9020-0454	9020-0455
Rated Voltage	230 V	115 V	208...230 V
Power frequency	50 Hz	60 Hz	60 Hz
Nominal power	1,6 kW	1,4 kW	1,8 kW
Unit fuse	10,0 A	15,0 A	10,0 A
Phase (Nominal voltage)	1~	1~	2~

Article Number	9020-0453	9020-0454	9020-0455
Interior volume	14 cu.ft.	14 cu.ft.	14 cu.ft.
Net weight of the unit (empty)	498 lbs	498 lbs	498 lbs
Permitted load of individual compartment	88 lbs	88 lbs	88 lbs
Permitted load	353 lbs	353 lbs	353 lbs
Wall clearance back	3,94 in	3,94 in	3,94 in
Wall clearance sidewise	9,84 in	9,84 in	9,84 in

Article Number	9020-0453	9020-0454	9020-0455
Width net	27.8 in	27.8 in	27.8 in
Height net	77.4 in	77.4 in	77.4 in
Depth net	36.93 in	36.93 in	36.93 in

Article Number	9020-0453	9020-0454	9020-0455
Interior width	19.13 in	19.13 in	19.13 in
Interior height	51.18 in	51.18 in	51.18 in
Interior depth	25.04 in	25.04 in	25.04 in
Inner doors	2	2	2
Unit doors	1	1	1

Article Number	9020-0453	9020-0454	9020-0455
Sound-pressure level	47 dB(A)	47 dB(A)	47 dB(A)
Average heat compensation at set value -80°C and Ta = 21°C	310 W	310 W	310 W
Energieverbrauch bei Sollwert -80 °C und Tᵤ = 20 °C	7.5 kWh/d	7.5 kWh/d	7.5 kWh/d

Article Number	9020-0453	9020-0454	9020-0455
Number of shelves (std./max.)	3/11	3/11	3/11

Article Number	9020-0453	9020-0454	9020-0455
Freezer racks per compartment	3	3	3
Cryoboxes, 50 mm	264	264	264

Binder® Model UF V 350, Ultra-low Temperature Freezers with Climate-Neutral Refrigerants, 25.9 Cu Ft (734 L), 120V

Technical specifications

Data

Performance Data Temperature

Electrical data

Dimensions and weights

Housing dimensions not incl. fittings and connections

Internal Dimensions

Environment-specific data

Fixtures

Load-variants
